13-3/4" x 60" KELLENBEBGER UNIVERSAL CYLINDRICAL GRINDER
                  Model Kel-Universal 1500U, New 2005, S/N 613867
                                             Stock# K14082
EQUIPPED WITH:
Heidenhain 2 Axis Digital Readouts, Swivel Base Headstock and Wheelhead,
Variable Speed Headstock, Machine Arrange for 3 Grinding Spindles, Left
Hand, Right Hand and ID Spindle. Power Rapid Traverse, Infeed for Plunge
Grinding, Sparkout Timer, Wheelheal Inch/Creep. Table Mounted Dresser,
Coolant System with Paper Filtration, Left and Right Wheel Guards.
Tooling.



CATALOGUE SPECIFICATIONS:
Swing Over Table, Maximum........................... 13-3/4"
Grinding Diameter, Maximum (with New Wheel)......... 13-3/4"
Grinding Length, Maximum............................ 60"
Distance Between Center, Maximum.................... 65"
Grinding Wheel, Standard Diameter................... 16"
Grinding Wheel, Hole Diameter....................... 5"
Wheelhead Swivel Range ............................. 180 DEG
Workhead Swivel Range............................... 360 DEG
Table Swivel Range.................................. +/- 6 DEG
Workhead Spindle Speeds, Infinite................... 20 to 400 RPM
Longitudinal Table Feeds, Infinite.................. 0 to 240 IPM
Wheelhead Motor..................................... 4 HP
Workhead Motor...................................... 2 HP
Electricals.........................................460/3/60
Approximate Machine Dimensions...................... 73" x 144"
Approximate Machine Height.......................... 70"
Approximate Weight.................................. 8,600 LBS



CONDITION:  Appears to be in Excellent Condition !!
