TY-MILES 8-TON VERTICAL PULL DOWN BROACH
MODEL# Rabbit MBLD-16-42-120R, Stock# K12575
EQUIPPED WITH:
Hydraulic In/Out Shuttle Table, Adjustable Saddle Broaches,
Automatic
Lubrication, Coolant Pump, Chip Conveyor.
SPECIFICATIONS:
Broaching Force, Maximum ............................... 8
Ton
Ram Stroke, Maximum .................................... 42"
Ram Speed, Maximum ..................................... 120 FPM
Shuttle Table Work Platen Dimensions ................... 9" x 12"
Hydraulic Motor ........................................ 20 HP
Electrics .............................................. 440/3/60
Approximate Machine Dimensions.......................... 80" X 48"
Approximate Machine Height.............................. 108"
Approximate Machine Weight.............................. 11,000.
CONDITION: Appears to be in Excellent Condition.
