Fanuc 0T CNC Control with CRT, RS232 Port, Graphics, Conversational
Programming, Thread Cutting, 20 M Additional Memory, 8 Position Gang Type
tool Slide, 6" Hydaulic Chuck, Chip Conveyor.
CATALOGUE SPECIFICATIONS:
Max Swing Over Bed......................................
19.68"
Max Swing Over Cross Slide..............................
6.69"
Max Part Diameter.......................................
12.6"
Max Part Length.........................................
8.86"
Standard Chuck Size.....................................
6"
Cross Travel (X-Axis)...................................
7.87"
Longitudinal Travel (Z-Axis)............................
9.25"
Rapid Traverse Rate (X-Axis)............................
600 IPM
Rapid Traverse Rate (Y-Axis)............................
600 IPM
Type of Tool Support....................................
Gang
Gang Positions.......................................... 8
Bar Capacity............................................
1.26"
Spindle Speed Range (1 RPM Increments)..................
60-6000 RPM
Spindle Horsepower......................................
10 HP
Approximate Machine Dimensions..........................
78" x 52"
Approximate Machine Height..............................
65"
Approximate Machine Weight..............................
6000 LBS
CONDITION: Machine Appears to be in Very Good Condition !
