EQUIPPED WITH:
Automatic Hydraulic Infeed, Plunge
Feed and Tarry, Hydraulic Table
Traverse, Rapid Wheelhead Advance and
Retract, Single Lever Control,
Infinitely Variable Table Traverse.
CATALOGUE SPECIFICATIONS:
Swing Over Table, Maximum
............................ 9-27/32"
Distance Between Centers
............................. 23-5/8"
Grinding Wheel, Standard Dia.
........................ 16"
Grinding Wheel, Standard Width
....................... 2"
Grinding Wheel, Hole Dia.
............................ 5"
Workhead Spindle Speeds
(Infinite).................... 10 to 400 RPM
Grinding Heed Speeds
(4)............................... 1500 - 3600 RPM
Longitudinal Table Feeds (Hydraulic)
................. .06 to 18 FPM
Automatic Infeed on Table
Reversal.................... .00005" - .0012"
Swivel of
Wheelhead................................... 270 Degrees
Swivel of
Workhead.................................... 360 Degrees
Table
Swivel.......................................... 11 Degrees
Electrical System
.................................... 440/3/60
Approximate Machine
Dimensions........................ 102" x 64" x 66"H
Approximate Machine
Weight............................ 6,100 lbs
CONDITION: Appears to be in Excellent
Condition !
