HAAS VF-6/50 CNC VERTICAL MACHINING CENTER
Model VF-6/50, S/N 9932, New 1997
Stock# K13208
EQUIPPED WITH:
HAAS 32-Bit CNC Control w/CRT, Helical
Interpolation, RS-232 Port, 4th
Axis Prewire, Floppy Disc Drive, Remote Jog Handle, Coordinate Scaling,
Programmable Coolant Nozzle, Inch or Metric Programming, Fanuc
compatibility, 100 Tool Offsets, 26 Work Coordinates, Tool Life
Management, Tool Load Monitoring, Background Editing, Heavy Duty 30 HP
Cat-50 Spindle, 20 Station Automatic Tool Changer, Rigid Tapping, Metal
Way Covers, Work Light, Chip Auger, Flood Coolant System with Full
Chip-Splash Enclosure.
CATALOGUE SPECIFICATIONS:
Table Working Surface............................. 64" x 28"
Table Load Capacity............................... 4,000 LBS
Longitudinal Travel (X-Axis)...................... 64"
Cross Travel (Y-Axis)............................. 32"
Vertical Travel (Z-Axis).......................... 30"
Maximum Clearance Table Top to Spindle Nose....... 34"
Feed Rates, All Axes.............................. 0 to 300 IPM
Rapid Traverse Rate, X-Axis....................... 540 IPM
Rapid Traverse Rate, Y and Z Axes................. 600 IPM
Tool Storage Capacity............................. 20
Spindle Horsepower................................ 30 HP
Spindle Speeds Range.............................. 0-7500 RPM
Spindle Taper..................................... No. 50 CAT (V-Flange)
Approximate Machine Dimensions.................... 123" x 156"
Approximate Machine Height........................ 128.5"
Approximate Machine Weight........................ 21,000 LBS
CONDITION: This Machine Appears to be in Very Good Condition !
