SNK CNC VERTICAL BRIDGE TYPE
MACHINING CENTER
Model RB6, New 2005, Stock# K13215
EQUIPPED WITH:
Fanuc CNC Control, 232 Port, Multiple Part Program Storage, Self
Diagnostics, 80 Station Automatic Tool Changer, Automatic Head
Changer, 90 Degree Head, 2-Axis Head, Heavy Duty Bridge Style
Design, 2 Range Geared Spindle, Manual Pulse Generator, Axis Error
Compensation, Cutter Compensation, Full Enclosure, Chiller, Coolant
System and Chip Conveyor.
CATALOGUE SPECIFICATIONS:
Table Working Surface................................. 236" x 118"
Table Load Capacity................................... 66,000 lbs
Longitudinal Travel (X-Axis).......................... 246"
Cross Travel (Y-Axis)................................. 150"
Vertical Travel (Z-Axis).............................. 27"
Crossrail Travel (W-Axis)............................. 80"
Spindle Nose to Table................................. 79"
Distance Between Columns.............................. 138"
Tool Storage Capacity................................. 80
Spindle Horsepower.................................... 40 HP
Spindle Speeds Range.................................. 50-8000 RPM
Spindle Taper......................................... #50 CAT
Electrics............................................. 460/3/60
CONDITION: Appears to be in Excellent Condition !
