KITAKO MT4-200 4-SPINDLE CNC TURNING CENTERS

  NEW 2006,  STK# K13520

EQUIPPED WITH:
FANUC 18I-TB (CONTROL)
HYDRAULIC CHUCK (8) X 4
TOTALLY ENCLOSED SPLASH GUARDS
DOOR INTERLOCK
CHIP CONVEYER
FOOT SWITCH
SERVO MOTOR DRIVEN CARRIER (2 SECOND INDEX TIME)
TOOL HOLDER FOR 8 STATION DRUM
HIGH PRESSURE COOLANT DEVICE
SIMPLE TOOL LIFE MGMT
MULTIPLE REPETITIVE CYCLES (G70)
CHAMFERING / CORNER ROUNDING
AIR BLOW CHUCKS
16" LIGHT CURTAIN

CATALOG SPECIFICATIONS:
NO. OF SPINDLES......................... 4 (2 FOR LOAD/UNLOAD, 2 FOR CUTTING)
MAX. TURNING DIAMETER................... 7.8"
MAX. TURNING LENGTH..................... 4.0"
POWER CHUCK SIZE........................ 8" 3-JAW HYDRAULIC CHUCKS
NO. OF TURRETS.......................... 2
NO. OF STATIONS PER TURRET.............. 8
TOOLING SHANK SIZE (O.D. TOOLS)......... 1.00"
BORING BAR DIAMETER (I.D. TOOLS)........ 1.50"
MAIN SPINDLE NOSE....................... A-2-6
MAIN SPINDLE SPEEDS..................... 40-4,000 RPM
X AXIS TRAVEL (CROSS)................... 6.69"
Z AXIS TRAVEL (LONGITUDINAL)............ 9.84"
RAPID FEED SPEED - X AXIS............... 787 IPM
RAPID FEED SPEED - Z AXIS............... 945 IPM
MAIN DRIVE MOTOR........................ 15 HP/20 HP (30 MIN)
CARRIER INDEX TIME...................... 2 SECONDS
MACHINE NET WEIGHT...................... 16,535 LBS

ONLY 6400 HOURS. APPEARS TO BE IN VERY GOOD CONDITION
