CATALOGUE SPECIFICATIONS:
Max Swing Over Slant Bed ................................... 22.00"
Max Swing Over Cross slide Ways............................... 12.5"
Max Machinable Center Distance.............................. 40"
Cross Travel (X-Axis)         Upper Slide Above Center...... 8.875"
                              Lower Slide Below Center...... 5.5"
Longitudinal Travel (Z-Axis)  Upper Slide................... 38"
                              Lower Slide .................. 44"
Feed Range X & Y-Axis (Infinitely Variable) ................. .1-200 IPM
Rapid Traverse Rate X & Y Axis ............................. 400 IPM
Tool Positions (8 on Each Turret)........................... 16 Total
Spindle Bore ............................................... 3.15"
Spindle Nose ............................................... A2-8
Spindle Speed Range ........................................ 88-3500 RPM
Spindle Horsepower.......................................... 50 HP
Approximate Machine Dimensions.............................. 208" x 96"
Approximate Machine Height.................................. 95"
Approximate Machine Weight.................................. 24,000 LBS



CONDITION:  Machine has Very Low Hours and Appears to be in
            Excellent Condition !
