MORI-SEIKI SL-154Y Multi Tasking CNC Turning Center with Live Tooling and Y-Axis

Stock Number K13666

Mori Seiki SL-154Y CNC Turning Center with Live Tooling and Y-Axis For Sale

ACTUAL PHOTOS

   2003 Mori Seiki SL-154Y CNC Turning Center with Live Tooling
         Model SL-154Y, New 2003

Equipped With:
MORIC MSG-805 (MITSUBISHI) CNC CONTROL, 10.4" Monochrome LCD ,
MAPPS Conversational Programming, C & Y-Axis Milling Capability,
8" Kitagawa B-208 Hydraulic Chuck, Coolant Thru Spindle (1000 psi ChipBlaster) ,
Mist Blaster, Auto Parts Catcher, Barfeed Interface, Tool Presetter,
Tow Along Tailstock, Turbo Chip Conveyor (Right Side Exit), Slant Bed Box Way Construction
(2) OD Live Holders, (2) Face Live Holders, (2) Boring Bar Holders, 80 Sets Tool Offsets
6 Sets Work Offsets.

Specifications:
Swing Over Bed                                                         26.8"
Swing Over Cross slide                                               20.1"
Between Centers                                                        22.6"
Max. Turning Dia                                                       11.8"
Spindle Speed Range                                                  5000 RPM
Spindle Nose                                                              A2-5
Bar Work Capacity                                                     1.77"
Spindle Motor                                                             10/7.5 HP
Turret Positions                                                          12 (All Live)
Live Tool Rotation Speed                                            3000 RPM
Milling Motor                                                              5 HP
Y-Axis Travel                                                            2.8"
C-Axis Indexing                                                         .001 Degree
Machine Weight                                                         9240 lbs.

Condition: Appears to be in very good condition.
