OKUMA CROWN BIG
BORE CNC
TURNING CENTER
Model CROWN BB, New 1999
EQUIPPED WITH:
Okuma U100L CNC Control w/CRT, One Touch IGF Programming, 10" 3-Jaw
Power Chuck, Linear and
Circular Interpolation, Bed Mounted Programmable Tailstock, Parts
Catcher, Berfeeder, Auto
Backlash Compensation, Auto Lube, Work Light, Coolant System, and Chip
Conveyor.
CATALOGUE SPECIFICATIONS:
Max Swing Over Saddle................................... 15.75"
Maximum Turning Diameter................................ 10.63"
Maximum Turning Length.................................. 19.68"
Standard Chuck Size..................................... 10"
Cross Travel (X-Axis)................................... 6.89"
Longitudinal Travel (Z-Axis)............................ 19.69"
Feed Range
(Infinitely Variable)........................ .1-400 IPM
Rapid Traverse Rate (X-Axis)............................ 787 IPM
Rapid Traverse Rate (Y-Axis)............................ 944 IPM
Number of Turrets....................................... 1
Tool Positions.......................................... 12 Total
Spindle Bore............................................ 3.15"
Spindle Nose............................................ A2-8
Spindle
Speed
Range
(1 RPM Increments).................. 65-3500 RPM
Spindle Horsepower...................................... 23 HP
Electrics............................................... 460/220/3/60
Approximate Machine Dimensions.......................... 104" x 73"
Approximate Machine Height.............................. 69"
Approximate Machine Weight.............................. 9,900 LBS
CONDITION: Machine Appears to be in Excellent Condition !
