EQUIPPED WITH:

Hardened and Ground Bed Ways, 12" 3-Jaw Chuck, 16" 4-Jaw Chuck, Aloris
Style Quick Change Tool Post, 9" Roller Type Steady Rest, Inch/Metric
Threading, Taper Attachment, 5-Position Carriage Stop, High Speed
Threading, Tailstock, Coolant Pans and Splash Guards.


CATALOGUE SPECIFICATIONS:

Swing Over Bed ........................................ 21"
Swing Over Cross Slide ................................ 14-1/2"
Distance Between Centers .............................. 120"
Spindle Nose .......................................... 11" D-1 Camlock
Spindle Hole .......................................... 3-9/16"
Bar Capacity .......................................... 3-1/2"
Spindle Drive ......................................... 12.5 HP
Spindle Speeds (16).................................... 18-1400 RPM
Longitudinal Feed Range ............................... .002" to .032"
Cross Feeds ........................................... .001" to .016"
Cross Slide Travel .................................... 14-1/2"
Compound Rest Travel .................................. 11"
U.S. Standard Threads (38)............................. 2-72 TPI
Metric Threads (40).................................... .4 to 40 mm
Electrics.............................................. 230/3/60
Approximate Dimensions ................................ 48"x 180"x 64"
Approximate Weight .................................... 8000 LBS

CONDITION: Machine Appears To Be In Very Good Condition!
