HARDINGE VMC-600  VERTICAL MACHINING CENTER
   Model VMC-600, New 2000, S/N MM223
      Stock# K14164



EQUIPPED WITH:



Fanuc 0M-D CNC Control w/CRT, RS-232 Port, Inch or Metric Programming,
Rigid Tapping, 20 Station Automatic Tool Changer, Flood Coolant System With Full Chip-Splash Enclosure.



CATALOGUE SPECIFICATIONS:



Table Working Surface.....................................  14" x 28-1/2"
Table Load Capacity......................................... 500 LBS
Longitudinal Travel (X-Axis)................................ 23.62"
Cross Travel (Y-Axis)........................................ 16.14"
Vertical Travel (Z-Axis)...................................... 20.08"
Maximum Clearance Table Top to Spindle Nose.. 23.4"
Rapid Traverse Rate, X & Y  Axes...................... 1181 IPM
Rapid Traverse Z-Axis....................................... 790 IPM
Tool Storage Capacity....................................... 20
Spindle Horsepower.......................................... 15 HP
Spindle Speeds Range...................................... 0-8000 RPM
Spindle Taper................................................... No. 40 CAT (V-Flange)
Electrics.......................................................... 220/3/60
Approximate Machine Dimensions..................... 118" x 96"
Approximate Machine Height............................. 103"
Approximate Machine Weight............................ 8,500 LBS



CONDITION: Appears to be in Excellent Condition !
