EQUIPPED WITH:
Acu-Rite 2-Axis Digital Readouts, 3" Spindle Bore, (1) Steady Rest, 12"
3-Jaw Chuck, Rapid Traverse, Inch Metric Threading, Compound Cross
Slide, Aloris Tool Post, Coolant System, Chip Pan.



CATALOGUE SPECIFICATIONS:
Swing over the bed................................. 20"
Swing over the cross slide......................... 11-1/2"
Swing in the Gap................................... 27-17"
Distance between centers........................... 80"
Cross Slide Travel................................. 10-1/2"
Spindle Nose....................................... D1-8
Spindle Bore....................................... 3-1/8"
Taper in Tailstock................................. MT-4
Spindle Speed (16)................................. 25-1500 RPM
Feed Range......................................... .0033-.0233 IPR
Metric Threads (39)................................ .25-6 mm
Inch Threads   (45)................................ 4-56 TPI
Main Motor......................................... 10 HP
Approximate Machine Dimensions..................... 40" x 110"
Approximate Machine Weight......................... 5000 lbs



CONDITION: Appears to be in Excellent Condition !
