EQUIPPED WITH:

Seicos L-III CNC Control w/ 12" CRT, Live Tooling, Programmable C-Axis, Y-Axis for Off Center Milling, 12 Position Automatic Tool Changer, 10 Position Turret, 2.5" Bar Capacity, Bed Mounted One Touch Programmable Tailstock, Auto Lube System, Tool Setter, Work Light, Chip Conveyor, Coolant System.

CATALOGUE SPECIFICATIONS:

Max Swing Over Bed...................................... 15.7"

Max Turning Diameter.................................... 14.1"

Max Machinable Center Distance.......................... 19.7"

Cross Travel (X-Axis)................................... 8.5"

Longitudinal Travel (Z-Axis)............................ 20.9"

Y Axis Travel........................................... 3"

Rapid Traverse Rate (X-Axis)............................ 787 IPM

Rapid Traverse Rate (Z-Axis)............................ 945 IPM

Rapid Traverse Rate (Y-Axis)............................ 400 IPM

Number of Turrets....................................... 1

Tool Positions.......................................... 10 Total

Toolchanger Capacity.................................... 12

Spindle Bore............................................ 3.15"

Bar Capacity............................................ 2.5"

Spindle Nose............................................ A2-8

Spindle Speed Range..................................... 20-3600 RPM

Spindle Horsepower...................................... 15 HP

Electrics............................................... 220/3/60

Approximate Machine Dimensions.......................... 130" x 96"

Approximate Machine Height.............................. 84"

Approximate Machine Weight.............................. 11,000 LBS

CONDITION: Machine Came from a First Class Facility Machining Medical Parts and Appears to be in Excellent Condition!
