Stock Number P11624

Stock# P11624

EQUIPPED WITH:

GE 2000 CNC Control, RS-232 Port, 49" 4-Jaw Chuck, 12 Station Automatic Tool Changer, Adjustable Cross Rail, Ram Head, Chip Conveyor, Coolant System.

CATALOGUE SPECIFICATIONS:

Maximum Swing........................................ 60"

Table Diameter....................................... 48.8"

Maximum Height Under Rail............................ 61"

Vertical Cross-Rail Travel........................... 43.3"

Vertical Ram Head Travel............................. 39.37"

Toolchanger Capacity................................. 12

Feed Rate, X & Z Axes................................ .1 - 40 IPM

Rapid Traverse Rate, X & Z Axes...................... 236 IPM

Chuck Speeds, Low Range.............................. 3.15 - 100 RPM

Chuck Speeds, High Range............................. 14 - 400 RPM

Spindle Motor........................................ 73.7 HP

Approximate Dimensions............................... 252" x 204"

Approximate Height................................... 156"

Approximate Weight................................... 55,000 LBS

CONDITION: Machine Appears to be in Excellent Condition !
