Port,
Axis Error Compensation, Fixture Offsets, Super Fast `Direct Change' 21
Station Automatic Tool Changer, Coolant System.
CATALOGUE SPECIFICATIONS:
Table Working Surface.................................
44"x20"
Table Load Capacity...................................
1,540 LBS
Longitudinal Travel (X-Axis)..........................
40"
Cross Travel (Y-Axis).................................
20"
Vertical Travel (Z-Axis)..............................
22"
Feed Rates (X & Y-Axes)...............................
0.1 to 787 IPM
Feed Rate (Z-Axis).................................... 0.1
to 708 IPM
Rapid Traverse Rate (X & Y-Axes)......................
787 IPM
Rapid Traverse Rate (Z-Axis).......................... 708
IPM
Tool Storage Capacity................................. 21
Spindle Horsepower.................................... 15
HP
Spindle Speeds Range..................................
60-8000 RPM
Spindle Taper......................................... #40
Approximate Machine Dimensions........................
138" x 100"
Approximate Machine Height............................
108"
Approximate Machine Weight............................
11,000 LBS
