CATALOGUE SPECIFICATIONS:

Working Surface Diameter..................................... 9"

Table Diameter............................................... 9"

Maximum Workload on Table 0 to 30 Degrees.................... 220 Lbs

Maximum Workload on Table 30 to 90 Degrees................... 220 Lbs

Table Center Height.......................................... 9.5"

Reduction Ratio Rotating..................................... 180:1

Reduction Ratio Tilting...................................... 360:1

Rotation Speed Rotating...................................... 11.1 RPM

Rotation Speed Tilting....................................... 5.5 RPM

Minimum Increment Rotating................................... .001 Deg.

Minimum Increment Tilting.................................... .001 Deg.

Approximate Dimensions....................................... 30" x 18"

Approximate Height........................................... 12"

Approximate Weight........................................... 490 LBS
