CATALOGUE SPECIFICATIONS:

Working Surface Diameter..................................... 6.5"

Table Diameter............................................... 6.5"

Horizontal Table Load Capacity............................... 500 Lbs.

Vertical Table Load Capacity................................. 180 Lbs.

Table Center Height.......................................... 6.5"

Maximum Diameter of Work Piece............................... 12.9"

T-Slot Size.................................................. .4375"

Ratio........................................................ 90:1

Spindle Brake Torque......................................... 300 Ft Lbs

Maximum RPM.................................................. 22.2 RPM

Approximate Dimensions....................................... 20" x 12"

Approximate Height........................................... 13"

Approximate Weight........................................... 165 LBS
