Meter,
Coolant System.
CATALOGUE SPECIFICATIONS:
Magnetic Chuck, Holding Diameter.....................
36"
Swing Inside Coolant Guards..........................
39"
Grind to Center Diameter.............................
36"
Vertical Capacity....................................
12"
Maximum Unbalanced Work Load on Chuck................ 3000
LBS
Chuck Rotation Speed................................. 6 to
33 RPM
Grinding Wheel Size..................................
18"
Grinding Wheel Speed................................. 720
RPM
Standard Wheel Size..................................
18"x5"x15"
Power Down Feeds (Grinding).......................... .004
to .080 IPM
Electrical System....................................
220-440/3/60
Approximate Machine Dimensions.......................
112" x 65"
Approximate Machine Height...........................
81"
Approximate Machine Weight........................... 12,900
LBS
CONDITION: Machine Appears to be in Excellent Condition!
