New 1989,
S/N 6429
EQUIPPED WITH: Power Feed on X Axis, Power Quill
Feed, 50" Table Length Option, 3 HP Variable
Speed Head, Knee Lock, Swivel Type Overarm.
SPECIFICATIONS:
Table Dimensions (Overall, W x L).........................
10" x 50"
Table Working Surface, W X L..............................
10" x 50"
Longitudinal Table Travel (X-Axis)........................
30"
Cross Saddle Travel (Y-Axis)..............................
12"
Vertical Knee Travel (W-Axis).............................
16"
Vertical Head Travel (Z-Axis).............................
5"
Spindle Speeds............................................
60-4200 RPM
Table Feeds...............................................
.75 - 35 IPM
Motor (Spindle)
........................................... 3 HP
Electrics................................................
220/440/3/60
Approximate Machine Dimensions............................
60" x 66"
Approximate Machine Height................................
85"
Approximate Machine Weight................................
2200 lbs.
Condition: Machine Appears to be in Very Good Condition!
