Touch
Screen Acramatic 2100 CNC Control w/Color CRT, Hand Held Pendant, Keyboard,
AC Spindle and Axis Drives, RS232 Data Line, Rugged CAT 50 Spindle, Coolant
System.
CATALOGUE SPECIFICATIONS:
Table Working Surface.................................
54" x 26"
Table Load Capacity................................... 3300
LBS
Longitudinal Travel (X-Axis)..........................
50"
Cross Travel (Y-Axis).................................
25.9"
Vertical Travel (Z-Axis)..............................
25.9"
Rapid Traverse Rate (X & Y-Axis)......................
945
Rapid Traverse Rate (Z-Axis).......................... 708
Tool Storage Capacity................................. 30
Spindle Horsepower.................................... 20 HP
Spindle Speed Range...................................
40-6000 RPM
Spindle Taper......................................... #50
CAT
Approximate Machine Dimensions........................
146"x138"
Approximate Machine Height............................
142"
Approximate Machine Weight............................
23,000 LBS
CONDITION: Machine appears to be in Excellent Condition !
