Color
Graphics, Operator Diagnostics, Multiple Part Program Storage, 26
Station Automatic Tool Changer, Heavy Duty 15 HP Geared Spindle with Cat
50 Spindle Taper, Flood/Mist Coolant System.
CATALOG SPECIFICATIONS:
Table Working Surface............................
84" x 26"
Table Load Capacity.............................. 8,000
LBS
Longitudinal Travel (X-Axis).....................
80"
Cross Travel (Y-Axis)............................
26"
Vertical Travel (Z-Axis).........................
25"
Maximum Clearance Table Top to Spindle Nose......
30"
Minimum Clearance Table Top to Spindle Nose......
5"
Feed Rates, All Axes............................. 0.5 to
150 IPM
Rapid Traverse Rate, All Axes.................... 480
IPM
Tool Storage Capacity............................ 26
Spindle Horsepower Continuous.................... 15 HP
Spindle Speed Range.............................. 25 -
6000 RPM
Spindle Taper.................................... #50
CAT V-Flange
Electrics........................................
230/460/3/60
Approximate Machine Dimensions...................
15'Lx13'W
Approximate Machine Height....................... 10'H
Weight, Approximate.............................. 25,000
LBS
CONDITION: Machine Appears to be in Very Good Condition
!
