Model LNC-8, New 1997
EQUIPPED WITH: Okuma OSP 700 CNC Control with CRT,
3.15" "Big Bore" Option, RS232 Port, 12 Position ID/OD
Tool Turret, Heavy Duty Slant Bed Construction, Coolant System.
CATALOGUE SPECIFICATIONS:
Max Swing Over Slant
Bed.................................. 15.75"
Max Swing Over
Carriage................................... 9.84"
Cross Travel
(X-Axis)..................................... 8.23"
Longitudinal Travel
(Z-Axis).............................. 19.68"
Feed Range (Infinitely Variable)
......................... .1 to 200 IPM
Rapid Traverse Rate
...................................... 591 IPM
Number of
Turrets......................................... 1
Turret
Positions.......................................... 12
Spindle
Bore.............................................. 3.15"
Spindle Speed
Range....................................... 75-4200 RPM
Spindle Drive
Motor....................................... 20 HP
Approximate Machine
Dimension............................. 107" x 70"
Approximate Machine
Height................................ 75"
Approximate Machine
Weight................................ 9,900 LBS
CONDITION: This Machine Came Out of a One Man Shop!
Original Owner, the Machine was Being used in His Garage! Machine
Appears to be in Excellent Condition !
