Model:
18CD, New 1967
EQUIPPED WITH: 36" Diameter Electro Magnetic
Chuck, 18" Segmented Grinding Wheel, Coolant System
CATALOGUE SPECIFICATIONS:
Magnetic Chuck, Holding Diameter......................
36"
Swing Inside Coolant Guards...........................
39"
Grind to Center Diameter..............................
36"
Vertical Capacity..................................... 18"
Maximum Unbalanced Work Load on Chuck................. 3000
LBS
Chuck Rotation Speed.................................. 6 to
33 RPM
Grinding Wheel Size...................................
18"
Grinding Wheel Speed.................................. 720
RPM
Standard Wheel Size...................................
18"x5"x15"
Power Down Feeds (Grinding)........................... .004
to .080 IPM
Approximate Machine Dimensions........................
120" x 65"
Approximate Machine Height............................
96"
Approximate Machine Weight............................
12,900 LBS
CONDITION: Machine Appears to be in Very Good Condition!
