CATALOGUE SPECIFICATIONS:

X-Axis Travel.......................................... 15.08"

Y-Axis Travel.......................................... 13.90"

Z-Axis Travel.......................................... 7.60"

A-Axis Maximum Swing................................... 13.15"

A-Axis Maximum Part Weight............................. 33 Lbs.

Positional Feedback Resolution (X, Y, & Z Axes)........ .00002"

Programming Resolution (X, Y & Z Axes)................. .0001"

Maximum Feedrate (X & Y Axes).......................... 256 IPM

Maximum Feedrate (Z-Axis).............................. 276 IPM

Approximate Machine Dimensions......................... 80" x 48"

Approximate Machine Height............................. 70"

Approximate Machine Weight............................. 3,960 lbs
