OSP
700L CNC Control,RS-232 Port,12 Position Turret, Chip Conveyor and
Coolant System.
CATALOGUE SPECIFICATIONS:
Max Swing Over Bed
..................................... 28"
Max Swing Over
Saddle................................... 18.9"
Max Tail Stock
Position................................. 48.78"
Spindle
Bore............................................ 3.62
Cross Travel
(X-Axis)................................... 9.05"
Longitudinal Travel
(Z-Axis)............................ 25.59"
Rapid Traverse Rate
(X-Axis)............................ 472 IPM
Rapid Traverse Rate
(Z-Axis)............................ 591 IPM
Tool
Positions.......................................... 12
Spindle Nose
........................................... A2-8
Spindle Speed
Range..................................... 52-3500 RPM
Spindle Drive
Motor..................................... 30/20 HP
Hydraulic Tailstock
Stroke.............................. 4.72"
Hydraulic Tailstock
Taper............................... #5 MT
Approximate Machine
Dimensions.......................... 135" x 72"
Approximate Machine
Weight.............................. 17,500 LBS
CONDITION: Machine Appears to be in Very Good
Condition !
