CATALOGUE SPECIFICATIONS:
Longitudinal Table Travel (X-Axis)................... 27.55"
Vertical Travel (Y-Axis)............................. 35.43"
Head Cross Travel (Z-Axis)........................... 30.71"
Pallet Dimensions.................................... 19.75" x
19.75"
Maximum Pallet Load.................................. 1,760 LBS
Number of Pallets.................................... 2
Number of Index Positions............................ 360
Feed Rate, All Axes.................................. .04 - 2362 IPM
Rapid Traverse, All Axes............................. 2362 IPM
Spindle Speed Range.................................. 50-6000 RPM
Spindle Taper........................................ #50 CAT
Number of Tool Positions............................. 100
Approximate Machine Dimensions....................... 224" x
122"
Approximate Machine Height........................... 129"
Approximate Machine Weight........................... 51,000 LBS
CONDITION: This Machine Appears to be in Excellent Condition!
