CATALOGUE SPECIFICATIONS:

Swing Over Table, Maximum............................. 16"

Grinding Diameter, Maximum (with New 14" Wheel)....... 16"

Maximum Between Centers............................... 32"

Wheelslide Angle...................................... 90 DEG

Grinding Wheel, Maximum Diameter (with New Wheel)..... 14"

Grinding Wheel, Maximum Width......................... 2"

Grinding Wheel, Hole Diameter......................... 5"

Table Feed Rates...................................... .01 - 200 IPM

Wheelhead Infeed Rapid Traverse Rate.................. 200 IPM

Wheelhead Infeed Resolution........................... .00001

Wheelhead Horsepower.................................. 10 HP

Wheelhead (Grinding Wheel) Speed...................... 1750 RPM

Workhead Speed (Infinitely Variable).................. 0-600 RPM

Approximate Machine Dimensions........................ 76" x 121" x 87"

Approximate Machine Weight............................ 15,500 LBS
