EQUIPPED WITH:

2 HP Hydraulic Unit, Adjustable Stroke and Daylight

CATALOGUE SPECIFICATIONS:

Maximum Stroke Length............................... 5-5/8"

Minimum Stroke Length............................... 2"

Maximum Daylight.................................... 9-1/2"

Minimum Daylight.................................... 7-1/2"

Table Length........................................ 34"

Table Width......................................... 16"

Hydraulic Motor..................................... 2 HP

Hydraulic Motor Speed............................... 1740 RPM

Flow Rate........................................... 1.96 GPM

Maximum Pressure.................................... 1450 PSI

Electrics........................................... 208/230/480/3/60

Approximate Machine Dimensions...................... 48" x 30"

Approximate Machine Height.......................... 48"

Approximate Machine Weight.......................... 1000 Lbs.
