CATALOGUE SPECIFICATIONS:

Maximum Amps.......................................... 50 Amps

Table Size............................................ 19.7" x 14.8"

Maximum Work Weight................................... 660 Lbs

Longitudinal Travel X-Axis............................ 11.8"

Cross Travel Y-Axis................................... 7.9"

Vertical Travel Z-Axis................................ 9.85"

Backslide Travel...................................... 7.9"

Electrode Diameters Available......................... .01" - .11"

Maximum Height of Workpiece........................... 8.6"

Electrics............................................. 9.84 IPM

Approximate Machine Dimensions........................ 51" x 65"

Approximate Machine Height............................ 85"

Approximate Machine Weight ........................... 2,000 LBS
