CATALOGUE SPECIFICATIONS:

Tonnage Capacity..................................... 100 Ton

Stroke Length........................................ 15"

Daylight, Maximum.................................... 32"

Throat Depth......................................... 14"

Main Cylinder Diameter............................... 8"

Ram Diameter......................................... 7"

Bed Area, L-R x F-B.................................. 29" x 21"

Motor, Horsepower/RPM................................ 20 HP/1160 RPM

Electrics............................................ 230/3/60

Approximate Machine Dimensions....................... 91" x 50"

Approximate Machine Height........................... 124"

Approximate Machine Weight........................... 20,000 LBS
