EQUIPPED WITH: Fanuc Oi-MD CNC Control, RS-232 Port, Multiple Part
Program Storage,20 Station Automatic Tool Changer, 30 HP (2) Speed Gearbox
Spindle, 14,200lb Table Load Capacity, Coolant System.
CATALOGUE SPECIFICATIONS:
Table Size............................................ 57" x
122"
Table Load Capacity................................... 14,200 Lbs.
Table Height from Floor............................... 33.5"
Spindle Nose to Table Minimum......................... 7.87"
Spindle Nose to Table Maximum......................... 38.5"
Distance Between Columns.............................. 66"
Longitudinal Travel (X-Axis).......................... 122"
Cross Travel (Y-Axis)................................. 59"
Vertical Travel (Z-Axis).............................. 30.7"
Rapid Traverse Rate All Axes.......................... 591 IPM
Tool Storage Capacity................................. 20
Spindle Horsepower (2-Speed Gearbox).................. 30 HP
Maximum Spindle Speed................................. 6000 RPM
Spindle Taper......................................... #50 CAT
Approximate Machine Dimensions........................ 354" x
216"
Approximate Machine Height............................ 177"
Approximate Machine Weight............................ 62,000 LBS
CONDITION: Machine Appears to be in Excellent Condition !
