EQUIPPED WITH:

OSP U-100M CNC Control with CRT, Automatic Pallet Changer, (2) 19.69"
Fully Contouring Pallets (360,000 Positions), Thru the Spindle Coolant,
40 Station Automatic Tool Changer, 12,000 RPM Spindle, Coolant System.


CATALOGUE SPECIFICATIONS:

Longitudinal Table Travel (X-Axis)................... 27.55"
Vertical Travel (Y-Axis)............................. 31.5"
Head Cross Travel (Z-Axis)........................... 27.55"
Pallet Dimensions.................................... 19.69" x 19.69"
Maximum Pallet Load.................................. 1,764 LBS
Number of Pallets.................................... 2
Number of Index Positions............................ 360,000
Spindle Speed Range.................................. 50-12,000 RPM
Spindle Taper........................................ No. 50
Number of Tool Positions............................. 40
Approximate Machine Dimensions....................... 195" x 137"
Approximate Machine Height........................... 128"
Approximate Machine Weight........................... 50,600 LBS


CONDITION: This Machine Has Been Cutting Aluminum Only and Appears to
be in Excellent Condition!
